600-850μm Ceramic Bead Blasting for Abrasive Refractory Industry

Place of Origin Changsha China
Brand Name Fine-Tech
Certification ISO9001
Model Number B20
Minimum Order Quantity 500kg
Price Negotiation
Packaging Details 25kg/barral, 25kg/bag, 1t/pallet
Delivery Time 5-15 work days
Payment Terms L/C, T/T
Supply Ability 2000t per year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Color White Finish Smooth
Usage Deburring Name Ceramic Cleaning Media
Shape Customizable Material Ceramic
High Light

1180um Ceramic Bead Blasting

,

Refractory Industry Bead Blasting Material

Leave a Message
Product Description

Product Description     &

Features:

Surface Treatment Consistency

The consistency of surface treatment is crucial for achieving a desired finish. When using ceramic shot, the blasting strength is comparable to steel balls, resulting in a much better surface finish than glass beads. This also allows for sufficient depth of metal to be achieved.

Environmental Friendly

Ceramic shot has a low crushing rate, produces no dust, has a uniform particle size and is highly wear resistant. In addition, it has the ability to rebound and maintain its original shape, eliminating the risk of silicosis. This makes it safe for human use.

Low Equipment Loss

The smooth surface, high sphericity, and good elasticity of ceramic shot make it less likely to wear down sandblasting equipment. This applies to both dry and wet sandblasting methods, ensuring the equipment is protected during use.

High Strength and Wear Resistance

Ceramic shot's main component is zirconia, which has a small crystal size and high wear resistance. It is also significantly harder than glass beads, with a Vickers hardness of 700hv and Rockwell hardness of 600hrc. Its density and specific gravity are also higher.

No Dust

Due to its high abrasion resistance and strength, ceramic shot is less likely to break during sandblasting, resulting in minimal dust generation.

High Sandblasting Efficiency

Ceramic shot has a smooth surface and high roundness, making it highly efficient for sandblasting. It can achieve a polished satin finish and requires 60-70% less material compared to glass bead sandblasting of the same specification.

Applicable to Various Materials

Ceramic shot is compatible with various metals and non-metals, including titanium alloy, magnesium alloy, aluminum alloy, stainless steel, carbon steel, brass, and acrylic and plastic materials. It does not react or oxidize with metal and leaves no metal residue, ensuring the color of the workpiece is not affected.

Long Service Life

Not only does ceramic shot have high sandblasting efficiency, but it also has a long service life. It can be recycled up to 25 times, making it a cost-effective choice.

High Roundness

Ceramic shot has a high roundness, resulting in a low proportion of abnormal or snowman balls adhering between the spheres. This guarantees a smooth surface for the workpiece after sandblasting.



Technical Parameters:

Attribute Value
Name Ceramic Cleaning Media
Usage Sandblasting
Process Bead Blasting
Shape Customizable
Color White
Zro2 65%
Cost Moderate
Size 850-1180μm
Application Abrasive Refractory Industry
Material Ceramic
Ceramic Bead Abrasive Yes
Ceramic Bead Blasting Yes
Ceramic Beads Blasting Media Yes


Applications:

Application of Ceramic Beads in Surface Treatment

Ceramic beads are commonly used in the blast pretreatment process before coating or plating. Among all surface cleaning methods, sandblasting with ceramic beads is considered to be a thorough, universal, and extensive method. It offers various benefits, including efficiency, cost-effectiveness, and flexibility, as described below.

Efficiency and Cost-effectiveness

Sandblasting with ceramic beads is known to be more efficient, thorough, and cost-effective compared to other pretreatment processes. Using clean compressed air, the beads are sprayed onto the surface of the workpiece, generating compressive stress and removing surface oxide film. This results in a clean and rough surface, perfect for mechanical bonding of the coating. This method is highly preferred for its ability to produce a uniform and uneven rough surface with high reactivity.

Flexibility in Surface Cleanliness and Roughness

One of the major advantages of sandblasting with ceramic beads is the ability to choose the desired level of surface cleanliness and roughness. This allows for customization based on the specific requirements of the workpiece, ensuring optimal bonding and appearance of the coating.

The quality of the pre-treatment process significantly impacts the adhesion, appearance, moisture resistance, and corrosion resistance of the coating. Poorly done pretreatment can lead to rusting under the coating, causing it to peel off.

Multiple Applications

Ceramic beads are widely used in various industries for different surface treatment purposes, such as:

  • Medical treatment: for deburring stainless steel surgical instruments and titanium alloy implanted devices.
  • High-iron field: for enhancing the metal texture and producing a smooth satin effect on high-iron aluminum alloy parts. Also used for grinding and finishing of high-speed rail components.
  • Automotive field: for cleaning and deburring automotive engine castings, welds, and welding spots. Also used for shot peening of automobile springs to improve fatigue life and for beautification of aluminum alloy wheels to eliminate stress and improve impact resistance.
  • Mold and machining: for sandblasting stainless steel, copper, and aluminum alloy molds to improve surface finish. Also used to clean flash and burr on machined parts.
  • Electronic equipment field: for sandblasting mobile phone, tablet, and watch shells made of aluminum alloy or stainless steel, to achieve desired surface roughness and gloss and prevent fingerprint marks.
  • Kitchen utensils industry: for sandblasting high-quality stainless steel cookware, pot bottoms, and soup spoons to impart a delicate metal texture and antibacterial properties.
  • Glass products industry: for atomization treatment of glass, replacing the use of hydrofluoric acid to prevent pollution.
  • Aviation industry: for shot peening of carbon steel, titanium alloy, aluminum alloy parts to improve fatigue resistance and eliminate surface stress. This is crucial for aircraft parts such as wings, turbine blades, and landing gear components.

In conclusion, sandblasting with ceramic beads is a highly effective and versatile method for surface treatment, offering various benefits and applications in different industries.



Customization:

Ceramic Bead Blasting Customization Service

Brand Name: Fine-Tech

Model Number: B20

Place of Origin: Changsha, China

Minimum Order Quantity: 500kg

Price: Negotiation

Packaging Details: 25kg/barrel, 25kg/bag, 1t/pallet

Delivery Time: 5-15 work days

Payment Terms: L/C, T/T

Supply Ability: 2000t per year

Zro2: 65%

Shape: Customizable

Color: White

Name: Ceramic Cleaning Media

Material: Ceramic

Our Ceramic Bead Blasting service, also known as Zirblast Ceramic Beads, offers high quality ceramic bead abrasive for all your blasting needs. Our ceramic blasting media is customizable and comes in a pure white color with a Zro2 content of 65%. With a minimum order quantity of 500kg, we offer competitive prices and flexible packaging options such as 25kg/barrel, 25kg/bag, and 1t/pallet. Our delivery time is 5-15 work days and we accept payment through L/C and T/T. With a supply ability of 2000t per year, we ensure prompt and efficient service for all your ceramic blasting needs.



Packing and Shipping:

Ceramic Bead Blasting Packaging and Shipping
Packaging:

Our Ceramic Bead Blasting products are carefully packaged to ensure safe delivery to our customers. Depending on the size and quantity of your order, our products are packaged in either of the following:

  • Cardboard boxes
  • Wooden crates
  • Steel drums

We also offer customized packaging options based on your specific requirements.

Shipping:

We ship our Ceramic Bead Blasting products to customers worldwide. We have partnered with reliable and efficient shipping companies to ensure timely and secure delivery of your order. We offer the following shipping options:

  • International air freight
  • Ocean freight
  • Ground transportation

We also provide tracking information for all orders so you can monitor the status of your shipment.

For international shipments, please note that additional customs fees and duties may apply. These charges are the responsibility of the customer.

For any special shipping requests, please contact our customer service team for assistance.

Thank you for choosing our Ceramic Bead Blasting products. We strive to provide the best packaging and shipping services to ensure your satisfaction with your order.



FAQ:

  • Q: What is the brand name of this product?
    A: The brand name of this product is Fine-Tech.
  • Q: What is the model number of this product?
    A: The model number of this product is B20.
  • Q: Where is this product manufactured?
    A: This product is manufactured in Changsha, China.
  • Q: What is the minimum order quantity for this product?
    A: The minimum order quantity for this product is 500kg.
  • Q: Is the price of this product negotiable?
    A: Yes, the price of this product is negotiable.
  • Q: What are the packaging details for this product?
    A: The packaging details for this product are 25kg/barral, 25kg/bag, and 1t/pallet.
  • Q: How long does it take for this product to be delivered?
    A: The delivery time for this product is 5-15 work days.
  • Q: What are the accepted payment terms for this product?
    A: The accepted payment terms for this product are L/C and T/T.
  • Q: What is the supply ability for this product?
    A: The supply ability for this product is 2000t per year.
